BF3603CS参考数据

Active pixel array:             653*493
Pixel size:                     2.2um*2.2um
Sensitivity:                    1.0V/lux.s
Dark current:                   3 mV/S at 40℃
Power supply:                   2.8v
Power consumption:              80mW @30fps and single 2.8V supply
Application:                    Cellphone,PC Camera
Standby current::               20uA
S/N Ratio:                      35dB
Dynamic range:                  58dB
Operating temperature           -30~80℃
Stable Image temperature:       -10~60 ℃
Optical format:                 1/10inch
Video mode:                     VGA(640*480)
Output formats:                 Bayer/RGB/YUV
Optimal lens chief ray angle:   29 ℃
Package:                        CSP,PLCC,COB
